ORK Nitrile Silicone Rubber Connector Seal Customized Color Industrial Oil Pump O Ring

ORK Nitrile Silicone Rubber Connector Seal Customized Color Industrial Oil Pump O Ring

ORK Nitrile connector seal

Silicone Rubber connector seal

Industrial oil pump o ring

Place of Origin:

Jiangxi, China

Brand Name:

ORK

Certification:

REACH / ROHS / ISO9001 / IATF / SGS / FDA

Model Number:

AS568 & PG Standard O-Rings

Contact Us
Request A Quote
Product Details
Size:
Customizable
Color:
Black
Material:
Rubber
Application:
Sealing For Connectors And Cables
OEM/ODM:
Acceptable
Usage:
Sealing Usage
Sample:
Freely Provided
Tensile Strength:
10 MPa
Chemical Resistance:
Excellent
Hardness:
70 Shore A
Uv Resistance:
Yes
Elongation At Break:
300%
Compression Set:
25%
Temperature Range:
-40°C To 120°C
Water Resistance:
Yes
Oil Resistance:
Yes
Shape:
Round
Highlight:

ORK Nitrile connector seal

,

Silicone Rubber connector seal

,

Industrial oil pump o ring

Payment & Shipping Terms
Minimum Order Quantity
1000 pieces
Price
$0.07/pieces 1000-4999 pieces
Packaging Details
PE bags inside , cartons outside , cartons on pallets. Or as your requirements .
Delivery Time
7-10 work days
Payment Terms
T/T , paypal , wechat , Alipay
Supply Ability
100000000000/week
Product Description

Customized Color ORK Nitrile Silicone Rubber O-Rings The Ideal Solution for Industrial



ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 0

Type: O Ring

Size: ID X CS, OD=ID + 2XCS

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 1

An o-ring is a simple and versatile ring-shaped packing or sealing device with a circular cross section (from
which the "O" in its name is derived). The purpose of using O-ring seals is to prevent leakage and loss of liquids
or gases. They simplicity,convenience, and small installation space. As long as the groove design and material
selection are correct, and the operating conditions are within the temperature range of the rubber material, the
seal can have a long-term sealing effect in the static or dynamic seal.
The size of o-ring is determined by the inner diameter ID and the wire diameter CS. O-ring size calculation:
outer diameter = inner diameter + 2 x wire diameter (OD = ID + 2x CS).


What An O Ring Can Apply For ?

Product Effects/Applications:

Product scope:Electrical Appliance, Hydraulic,Automobile, Furniture, Machinery, Electronic, Household, Medical,

Water industry,Food industry etc.

Solution:Oil seal,Air seal,Water-proof,Solvent resistant,Heating Resistant,Dust Free,shock absorber,skid resistant,

Decoration.

Our Service for O-Ring



O Rings are one of our main products.We have VITON o-rings, Silicone O Ring, EPDM O Ring, NBR O Ring, HNBR

O Ring, NR O Ring, Neoprene O Ring, Dupont Viton O Ring, FFKM O Ring, FVMQ O Ring, Aflas O Ring, etc.



We are specialized in the manufacturing kinds of rubber products for more than 30 years. We can design and produce

flat silicone rubber o-ring according to your drawings & samples. If you are interested in our flat silicone rubber o-ring ,

plaese don't hesitate to contact us. And before we can quote you our best price, pls let us know some points:



What is your quantity? This will change the unit price of rubber o-ring.

Where is the destination? We will figure out the freight for you.



Product name O-RING
Material NR, NBR, EPDM, SBR, VITON, CR, SILICONE, FLUOROSILICONE, ACM,  HNBR ,IIR
Color Black, Brown, Orange-Red, or as pantone card, CUSTOMIZED

Standard Sizes



ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 2

• AS 568 Standard Sizes:

• Cross Section:1.78mm/2.62mm/3.53mm/5.33mm/6.99mm

• JIS B 2401 Standard Sizes:

• P type Cross Section:1.9mm/2.4mm/3.5mm/5.7mm/8.4mm

• G type Cross Section:3.1mm/5.7mm

• V type Cross Section:4mm/6mm/10mm

• S type Cross Section:1.5mm/2mm

Hardness 30-90 Shore A, Normal is 70 Shore A
Temperature -40~150℃, 300℃, CUSTOMIZED
Package CUSTOMIZED



We can supply material as NBR, FKM, SIL, EPDM, CR, NR, PU, HNBR, FFKM, ACM ,SBR , FLS , etc...





Material Hardness
(Shore A)
Temperature
(ºC)
Main Color Advantage Price Level Shelf Life
(Years)
NBR / Nitrile / Buna-N 60-90 -40 - 120 Black Good oil resistance & low price Low 5-10
HNBR / HSN 60-90 -40 - 150 Green Suitable for the cooling industry High 5-10
FKM / FPM / Viton 70-90 -20 - 200 Brown High-temperature & chemical resistance High About 20
EPDM / EPR 50-90 -50 - 150 Black Excellent weather & ageing resistance Fair 5-10
VMQ / Silicone 40-80 -70 - 220 Red High-temperature & FDA food grade High About 20
Neoprene / CR 50-90 -40 - 120 Black Versatility Properties Fair 5-10
FFKM 70-90 -10 - 320 Black Excellent chemical & high-temperature Highest About 20
FVMQ / Fluorosilicone 40-80 -60 - 200 Blue Wider operating temperature range High About 20
Aflas / FEPM 40-90 -2 - 230 Black Good chemical compatibility Higher About 20
PU / polyurethane 60-90 -40 - 90 Natural High strength and wear resistance High About 10



We have certificates :ISO 9001:2015 , ISO 14001:2015 ,ISO 45001:2018 , IATF , FDA, REACH, ROHS, SGS etc.

IATF 16949 2016.pdf

ISO 9001 2015.pdf

ISO45001.pdf

ISO 14001.pdf

NBR-ROHS CANEC23015740929(SZP23-030677).pdf

NBR-REACH CANEC23015740931(SZP23-030677).pdf

Datesheet-NBR 65 Black(N6501).pdf



For color , we can make as customers' requirements .Below table is the colorful o rings

we made.If you need colored o rings , you can give me pantone number .

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 3





We can also produce Automotive Rubber Seals ,Connector Rubber Seals ,Power Tool Rubber seals ,Valve

Rubber Seals ,Pipe Rubber Seals ,Semiconductor Rubber Seals ,Hydraulic Pneumatic Rubber Seals ,Pump

Rubber Seals ,Oil and Gas Seals ,Food Grade Rubber Seals ,Medical Rubber Seals ,Chemical Equipment

Rubber Seals ...etc.

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 4

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 5

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 6

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 7

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 8

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 9

Our Factory



1. Since 2006, focus on rubber seals, especially for auto parts


2. Certificates: ISO9001, IATF16949, ISO14001, ISO45001,ISO 13485


3. Two factories, more than 18000㎡,clean room 600㎡, with 300 workers.



4. Molds > 10000 sets, especially o rings, about 5000 sets.



5.O-ring series covers American standard (AS568), Japanese standard (JIS), national

standard(GB), and produces a large number of customized non-standard parts.



6. Material: NBR, FKM, SIL, EPDM, CR, NR, PU, HNBR, FFKM, SBR .The rubber materials

used meet the requirements of ROHS2.0 and REACH235.



7. Material Certificates: FDA, ROHS, REACH, UL157, CP65 WRC, EN549,EN45545.



8. Products are widely used in automotive parts, electronic connectors, valves, pneumatics,
power tools, new energy, medical equipment, electronic products and other fields.



9. company has introduced HRP, ERP and other systems since its inception.

10. The company's labor cost, raw material procurement, production process and
product quality were comprehensively and scientifically controlled.

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 10ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 11ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 12



Ruichen always meets our customers' requirements. To make sure we produce high-quality o-rings, our company implements the

following general standards:

1) Raw material incoming inspection standard ASTM D2000 & HG/T 2579-2008 & HG/T 2811-1996
2) Public o-ring dimensional tolerance GB/T 3452.1-2005
3) N-level specification for o-ring appearance quality inspection GB/T 3452.2-2007
4) Hardness measurement model Micro O-Ring Testing (Type M system)
5) Hardness using standard ASTM D2240 Rubber Standard Test Method (Shore A)
6) Sampling inspection specification GB/T2828.1-20



Progress
ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 13



Quality control



Material Inspection:Storage of all raw materials before the test, and issue a report on the

corresponding material properties, compared with raw material's own property report, two

reports property values is consistent, can put in storage.

Model Inspection:After the mold development or mold cleaning finished on the machine, we

will test all the specifications of the mold to ensure that each cavity of the product specifications

and quality.

Production Inspection:The production process of the product inspection personnel timing

semi-finished product inspection, ensure the quality of the rationality of technology, defective

rate control in a reasonable range.
Quanlity Control:The quality inspection department will conduct a sampling inspection of

each batch of products
Production Full Inspection:The optical inspection machine can ensure the appearance and

dimension of the product are 100% qualified.





Cooperative partner



Ruichen company have cooperated with many superior customers as below , we have complete system and excellent productivity

to serve for you

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 14



International exhibition



ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 15

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 16

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 17

ORK Nitrile Silicone Rubber Connector Seal Customized Color  Industrial Oil Pump O Ring 18

Why RUICHEN?

Many big companies select RUICHEN for their rubber seals and customized rubber parts because we always

satisfy them in quality, price, delivery, service, etc. At the same time, we also attach great importance to the

small customers in niche markets.Whether your purchase quantity is big or small, you are our valuable partners.

High Quality
We continue to manufacture high-quality products for all customers and pursue 100% customer satisfaction,

which has become one of our core competencies.

Profession
We have rich experience in materials, products, and production and excellent international trade and language

communication skills.

Best Services
From quoting, sampling, production, and shipping to after-sales, our sales will provide you with the best service

so that you can rest assured completely.

10000+ Projects Delivered
Over 10K projects have been sent to our customers worldwide in recent years, and we have received countless

positive comments.

Low Price
Our customers can obtain maximum profits through the ISO management system and intelligent manufacturing

to reduce our costs continuously.

Massive Capacity
Our in-house facilities allow us to get your projects done fast. And thanks to our strong relationship with rapid

materials partners, our capacity is not limited.

Fast Delivery
Unlimited capacity, experienced engineers, and a flexible production system allow us to create your seals and

production parts in a short period.

1000+ Happy Customers
We aim to keep every customer happy with reliable quality, fast turnaround, and excellent services. We want all

our new customers to become long-term customers.

FAQ

Q: 1 What kinds of materials can you provide?
A: NBR, EPDM, SILICONE,FKM(FKM),NEOPRENE(CR), HNBR ,NR, IIR, SBR, ACM, AEM,Fluorosilicone(FVMQ),

FFKM etc.
Q: 2 How to select the raw compound for my application?
A: With years of experience working with a variety of material, we can help select the material that will best suit your

needs while keeping material costs in mind.
Q: 3 How long can we get the quote?
A: If your information is complete, we will provide the quotation within 8 hours.
Q: 4 Can you provide samples? Is it free or extra?
A: Yes, we can provide samples for free. Freight can be negotiated.



Q: 5 What is the normal lead time for product orders?
A: If the stock generally takes 3-7 days, mold about 15-18 days, no mold about 25-30 days, depending on the product

situation.



Q: 6 How to check the quality of the bulk order?
A: We have incoming inspection, control the quality of raw materials, process inspection,to ensure the quality of the

production process, shipping 100% of the full inspection; automatic inspection machine full inspection, and according

to customer needs before the mass production of pre-production samples.



Q: 7 What is your standard packing?
A: Plastic bag for inner packing .carton box for outer packing also be packed according to customer's requirements.



Q: 8 What's the payment term?
A: We accept T/T 30% deposit and 70% balance ,Paypal is also ok
