Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees

Silicone medical rubber ring

medical rubber ring custom Sizes

thin rubber o rings 250 degrees

Place of Origin:

Jiangxi, China

Brand Name:

ORK

Certification:

REACH / ROHS / ISO9001 / IATF / SGS / FDA

Model Number:

AS568 & PG Standard O-Rings

Contact Us
Request A Quote
Product Details
Size:
AS568 & PG Standard Size
Fda Compliance:
Compliant With FDA Regulations For Medical Devices
Compression Set:
Less Than 20%
Low Extractables:
Minimal Leaching Of Substances
Chemical Resistance:
Resistant To Most Chemicals And Solvents
Non-Toxic:
Does Not Contain Harmful Substances
Material:
Medical Grade Rubber
Sterilization Methods:
Autoclave, Gamma Radiation, Ethylene Oxide
Hardness:
70 Shore A
Temperature Resistance:
Up To 250 Degrees Celsius
Tensile Strength:
10 MPa
Color:
Transparent
Non-Allergenic:
Does Not Cause Allergic Reactions
Biocompatibility:
Biocompatible With Human Tissue And Fluids
Elongation At Break:
500%
Customizable:
Can Be Customized To Fit Specific Applications
Highlight:

Silicone medical rubber ring

,

medical rubber ring custom Sizes

,

thin rubber o rings 250 degrees

Payment & Shipping Terms
Minimum Order Quantity
1000 pieces
Price
$0.08/pieces 1000-4999 pieces
Packaging Details
PE plastic bags then to the carton / as per your request
Delivery Time
7-10 work days
Payment Terms
T/T , paypal , wechat , Alipay
Supply Ability
10000000 Piece/Pieces per Day
Product Description

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees



Type: O Ring

Size: ID X CS, OD=ID + 2XCS

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 0

An o-ring is a simple and versatile ring-shaped packing or sealing device with a circular cross section (from
which the "O" in its name is derived). The purpose of using O-ring seals is to prevent leakage and loss of liquids
or gases. They simplicity,convenience, and small installation space. As long as the groove design and material
selection are correct, and the operating conditions are within the temperature range of the rubber material, the
seal can have a long-term sealing effect in the static or dynamic seal.
The size of o-ring is determined by the inner diameter ID and the wire diameter CS. O-ring size calculation:
outer diameter = inner diameter + 2 x wire diameter (OD = ID + 2x CS).


What An O Ring Can Apply For ?

Product Effects/Applications:

Product scope:Electrical Appliance, Hydraulic,Automobile, Furniture, Machinery, Electronic, Household, Medical,

Water industry,Food industry etc.

Solution:Oil seal,Air seal,Water-proof,Solvent resistant,Heating Resistant,Dust Free,shock absorber,skid resistant,

Decoration.

Our Service for O-Ring



O Rings are one of our main products.We have VITON o-rings, Silicone O Ring, EPDM O Ring, NBR O Ring, HNBR

O Ring, NR O Ring, Neoprene O Ring, Dupont Viton O Ring, FFKM O Ring, FVMQ O Ring, Aflas O Ring, etc.



We are specialized in the manufacturing kinds of rubber products for more than 30 years. We can design and produce

flat silicone rubber o-ring according to your drawings & samples. If you are interested in our flat silicone rubber o-ring ,

plaese don't hesitate to contact us. And before we can quote you our best price, pls let us know some points:



What is your quantity? This will change the unit price of rubber o-ring.

Where is the destination? We will figure out the freight for you.



Product name O-RING
Material NR, NBR, EPDM, SBR, VITON, CR, SILICONE, FLUOROSILICONE, ACM, CSM, ECO, HNBR
Color Black, Brown, Orange-Red, or as pantone card, CUSTOMIZED

Standard Sizes



Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 1

• AS 568 Standard Sizes:

• Cross Section:1.78mm/2.62mm/3.53mm/5.33mm/6.99mm

• JIS B 2401 Standard Sizes:

• P type Cross Section:1.9mm/2.4mm/3.5mm/5.7mm/8.4mm

• G type Cross Section:3.1mm/5.7mm

• V type Cross Section:4mm/6mm/10mm

• S type Cross Section:1.5mm/2mm

Hardness 30-90 Shore A, Normal is 70 Shore A
Temperature -40~150℃, 300℃, CUSTOMIZED
Package CUSTOMIZED



Silicone O-Rings Selection Guide

Silicone o-rings are excellent seal materials for high temperatures in static environments. Typically, silicone

o-rings show outstanding flex and fatigue life, strong ozone and UV radiation resistance, and physiologically

neutral and insulating properties. Silicone o-rings can be synthesized with a wide variety of properties and

compositions, allowing for great flexibility in performance.

ORK Rubber has millions of standard and non-standard silicone o-ring sizes in-stock, and the ability to

custom-make o-rings upon request, often without tooling fees. Order silicone o-rings from the world’s largest

o-ring inventory network, including:

· High temperature silicone gaskets and o-rings

· FDA food grade silicone seals and o-rings

· USP Class VI medical-grade silicone gaskets and o-rings

Common Names

Silicone, VMQ, PVMQ

Trade Names

Silastic®, Elastosil®, Thermoflex®

Features

The term silicone covers a large group of materials in which vinyl-methyl-silicone (VMQ) is often the central ingredient.

· Can be compounded to meet FDA, USP Class VI, USDA, 3-A and Canada AG

· Excellent heat and compression resistance, excellent flexibility, good electrical insulator

· Excellent resistance to oxygen, ozone and sunlight, animal and vegetable oil and grease

· Resistance to fungal and biological attack

Specialty Resistances

· Dry Heat

· Wide Temperature Range

· Sunlight, Ozone, Weathering

· Odorless and Non-Toxic

Limitations

· Not Resistant to Ketones (MEK)

· Not Resistant to Acids or Alkalis

· Not Resistant to Silicone Oils

· Not Resistant to Brake Fluids

· Low Strength and Poor Abrasion Resistance

· High Gas Permeability

· Concentrated Solvents, Oils or Concentrated Acids

· Aromatic Hydrocarbons (Benzene, Toluene)

· Superheated Water or Steam Over 250 F

· Diluted Sodium Hydroxide, Hydrocarbon Based Fuels or Aromatic Mineral Oil

Mechanical Properties

· Poor Wear Resistance

· Excellent Comp. Set Resistance

· Poor Short-Term Resilience

· Excellent Permeation Resistance



We can supply material as NBR, FKM, SIL, EPDM, CR, NR, PU, HNBR, FFKM, ACM ,SBR , FLS , etc...





Material Hardness
(Shore A)
Temperature
(ºC)
Main Color Advantage Price Level Shelf Life
(Years)
NBR / Nitrile / Buna-N 60-90 -40 - 120 Black Good oil resistance & low price Low 5-10
HNBR / HSN 60-90 -40 - 150 Green Suitable for the cooling industry High 5-10
FKM / FPM / Viton 70-90 -20 - 200 Brown High-temperature & chemical resistance High About 20
EPDM / EPR 50-90 -50 - 150 Black Excellent weather & ageing resistance Fair 5-10
VMQ / Silicone 40-80 -70 - 220 Red High-temperature & FDA food grade High About 20
Neoprene / CR 50-90 -40 - 120 Black Versatility Properties Fair 5-10
FFKM 70-90 -10 - 320 Black Excellent chemical & high-temperature Highest About 20
FVMQ / Fluorosilicone 40-80 -60 - 200 Blue Wider operating temperature range High About 20
Aflas / FEPM 40-90 -2 - 230 Black Good chemical compatibility Higher About 20
PU / polyurethane 60-90 -40 - 90 Natural High strength and wear resistance High About 10



We have certificates :ISO 9001:2015 , ISO 14001:2015 ,ISO 45001:2018 , IATF , FDA, REACH, ROHS, SGS etc.

IATF 16949 2016.pdf

ISO 9001 2015.pdf

ISO45001.pdf

ISO 14001.pdf
SIL-ROHS CANEC23015740921(SZP23-030677).pdf

SIL-REACH CANEC23015740923(SZP23-030677).pdf

SIL-FDA CANEC23015737709(SZP23-030799).pdf

For color , we can make as customers' requirements .Below table is the colorful o rings

we made.If you need colored o rings , you can give me pantone number .

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 2





We can also produce Automotive Rubber Seals ,Connector Rubber Seals ,Power Tool Rubber seals ,Valve

Rubber Seals ,Pipe Rubber Seals ,Semiconductor Rubber Seals ,Hydraulic Pneumatic Rubber Seals ,Pump

Rubber Seals ,Oil and Gas Seals ,Food Grade Rubber Seals ,Medical Rubber Seals ,Chemical Equipment

Rubber Seals ...etc.

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 3

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 4

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 5

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 6

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 7

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 8

Our Factory



Rui Chen Sealing Co., Ltd was built in 2006, now there are more than 200 staff. The company has

two branches in Guangdong

and Jiangxi, They are Dongguan Rui Chen Sealing Co., Ltd. and Shangrao Rui Chen Sealing Co., Ltd..

In recent years, the company has been supported by ShangRao municipal government and fully enjoy

all the preferential policies

for economic development zone. We will always take "best quality, best service" as our mission, and make

progress together with you, harmony and mutual win!

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 9Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 10Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 11



Ruichen always meets our customers' requirements. To make sure we produce high-quality o-rings, our company implements the

following general standards:

1) Raw material incoming inspection standard ASTM D2000 & HG/T 2579-2008 & HG/T 2811-1996
2) Public o-ring dimensional tolerance GB/T 3452.1-2005
3) N-level specification for o-ring appearance quality inspection GB/T 3452.2-2007
4) Hardness measurement model Micro O-Ring Testing (Type M system)
5) Hardness using standard ASTM D2240 Rubber Standard Test Method (Shore A)
6) Sampling inspection specification GB/T2828.1-20



Progress
Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 12



Cooperative partner



Ruichen company have cooperated with many superior customers as below , we have complete system and excellent productivity

to serve for you

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 13



International exhibition



Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 14

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 15

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 16

Silicone Medical Rubber Ring Thin Rubber O Rings Custom Sizes 250 Degrees 17

Why RUICHEN?

Many big companies select RUICHEN for their rubber seals and customized rubber parts because we always

satisfy them in quality, price, delivery, service, etc. At the same time, we also attach great importance to the

small customers in niche markets.Whether your purchase quantity is big or small, you are our valuable partners.

High Quality
We continue to manufacture high-quality products for all customers and pursue 100% customer satisfaction,

which has become one of our core competencies.

Profession
We have rich experience in materials, products, and production and excellent international trade and language

communication skills.

Best Services
From quoting, sampling, production, and shipping to after-sales, our sales will provide you with the best service

so that you can rest assured completely.

10000+ Projects Delivered
Over 10K projects have been sent to our customers worldwide in recent years, and we have received countless

positive comments.

Low Price
Our customers can obtain maximum profits through the ISO management system and intelligent manufacturing

to reduce our costs continuously.

Massive Capacity
Our in-house facilities allow us to get your projects done fast. And thanks to our strong relationship with rapid

materials partners, our capacity is not limited.

Fast Delivery
Unlimited capacity, experienced engineers, and a flexible production system allow us to create your seals and

production parts in a short period.

1000+ Happy Customers
We aim to keep every customer happy with reliable quality, fast turnaround, and excellent services. We want all

our new customers to become long-term customers.

FAQ

Q: 1 What kinds of materials can you provide?
A: NBR, EPDM, SILICONE,FKM(FKM),NEOPRENE(CR), HNBR ,NR, IIR, SBR, ACM, AEM,Fluorosilicone(FVMQ),

FFKM etc.
Q: 2 How to select the raw compound for my application?
A: With years of experience working with a variety of material, we can help select the material that will best suit your

needs while keeping material costs in mind.
Q: 3 How long can we get the quote?
A: If your information is complete, we will provide the quotation within 8 hours.
Q: 4 Can you provide samples? Is it free or extra?
A: Yes, we can provide samples for free. Freight can be negotiated.



Q: 5 What is the normal lead time for product orders?
A: If the stock generally takes 3-7 days, mold about 15-18 days, no mold about 25-30 days, depending on the product

situation.



Q: 6 How to check the quality of the bulk order?
A: We have incoming inspection, control the quality of raw materials, process inspection,to ensure the quality of the

production process, shipping 100% of the full inspection; automatic inspection machine full inspection, and according

to customer needs before the mass production of pre-production samples.



Q: 7 What is your standard packing?
A: Plastic bag for inner packing .carton box for outer packing also be packed according to customer's requirements.



Q: 8 What's the payment term?
A: We accept T/T 30% deposit and 70% balance ,Paypal is also ok



Send your inquiry directly to us

Privacy Policy China Good Quality Automotive Rubber Seals Supplier. Copyright © 2024 SHANGRAO RUICHEN SEALING CO.,LTD . All Rights Reserved.
