Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing

Place of Origin:

Jiangxi, China

Brand Name:

ORK

Certification:

REACH / ROHS / ISO9001 / IATF / SGS / FDA

Model Number:

As per buyer's drawing

Contact Us
Request A Quote
Product Details
Size:
As Per Buyer's Drawing, As Per Drawing Dimensions
OEM/ODM:
Accepptable
Material:
Fluorine Rubber
Colour:
Any Color Is OK
Hardness Range:
30-90 Shore A
Application:
Medical Devices, Pharmaceutical Equipment, Laboratory Equipment
Standard Or Nonstandard:
Standard
Medical Grade:
Yes
Sterilization Methods:
Autoclave, Ethylene Oxide, Gamma Irradiation
Fda Compliance:
Yes
Temperature Resistance:
Up To 200°C
Size Range:
Customizable
Biocompatibility:
ISO 10993-5 And USP Class VI Certified
Chemical Resistance:
Excellent
Surface Finish:
Smooth
Payment & Shipping Terms
Minimum Order Quantity
1000 pieces
Price
$0.07/pieces 1000-4999 pieces
Packaging Details
PE bags inside , cartons outside , cartons on pallets. Or as your requirements .
Delivery Time
7-10 work days
Payment Terms
T/T , paypal , wechat , Alipay
Supply Ability
100000000000/week
Product Description

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 0



The standard of O-rings mainly includes: national standard GB1235-76, national standard GB3452.1-92;

Japanese standard PTYPE, GTYPE, STYPE, SS/VTYPE, FTYPE; American standard AS568, British standard

series; European standard series

O-ring technical requirements include appearance requirements, dimensional requirements, and material physical

performance requirements.

Appearance requirements in line with GB/T3452.2-2007

Material requirements are in line with HG/T2579-2008

Dimensional requirements are in line with GB/T3452.1-2005



Product name O-RING
Material NR, NBR, EPDM, SBR, VITON, CR, SILICONE, FLUOROSILICONE, ACM, PU,IIR , HNBR
Color Black, Brown, Orange-Red, or as pantone card, CUSTOMIZED

Standard Sizes



Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 1

• AS 568 Standard Sizes:

• Cross Section:1.78mm/2.62mm/3.53mm/5.33mm/6.99mm

• JIS B 2401 Standard Sizes:

• P type Cross Section:1.9mm/2.4mm/3.5mm/5.7mm/8.4mm

• G type Cross Section:3.1mm/5.7mm

• V type Cross Section:4mm/6mm/10mm

• S type Cross Section:1.5mm/2mm

Hardness 30-90 Shore A, Normal is 70 Shore A
Temperature -40~150℃, 300℃, CUSTOMIZED
Package CUSTOMIZED



Different elastomers have different compatibility with various chemical elements and their characteristics.

See the table below for more material knowledge to order the most cost-effective o-rings from us.



Material Hardness
(Shore A)
Temperature
(ºC)
Main Color Advantage Price Level Shelf Life
(Years)
NBR / Nitrile / Buna-N 60-90 -40 - 120 Black Good oil resistance & low price Low 5-10
HNBR / HSN 60-90 -40 - 150 Green Suitable for the cooling industry High 5-10
FKM / FPM / Viton 70-90 -20 - 200 Brown High-temperature & chemical resistance High About 20
EPDM / EPR 50-90 -50 - 150 Black Excellent weather & ageing resistance Fair 5-10
VMQ / Silicone 40-80 -70 - 220 Red High-temperature & FDA food grade High About 20
Neoprene / CR 50-90 -40 - 120 Black Versatility Properties Fair 5-10
FFKM 70-90 -10 - 320 Black Excellent chemical & high-temperature Highest About 20
FVMQ / Fluorosilicone 40-80 -60 - 200 Blue Wider operating temperature range High About 20
Aflas / FEPM 40-90 -2 - 230 Black Good chemical compatibility Higher About 20
PU / polyurethane 60-90 -40 - 90 Natural High strength and wear resistance High About 10



FKM, FPM(Fluorocarbon)

Material FKM/FPM
Advantage 1,Excellent High Temperature Resistance
2. Excellent Abrasion-Resistance
3,Excellent Oil Resistance
4.Excellent Weathering Resistance
5.Excellent Ozone Resistance
6.Good Water Resistance
Disadvantage 1.Poor Low Temperature Resistance
2.Poor Oxygenated-Solvent Resistance
Temperature -20℃~250℃ , -40℃~250℃(special formula)
Application 1.For Auto
2.For Aerospace
3.For Electronic Products

*Service Temperature
For general type FKM the service temperature is better limited to approximately from -26 C to 232 C in static

applications, though the service temperature can arrive to 275 C at short time In dynamic applications, it is

suitable between -15 C and 200 C.

*Application
Because FKM has excellent resistance of high temperature, oil, solvent, flame, chemicals and weathering, it is

usually applied in automotive, chemical processing, aerospace and many other industries.



We have certificates :ISO 9001:2015 , ISO 14001:2015 ,ISO 45001:2018 , IATF , FDA, REACH,ROHS, SGS etc.

IATF 16949 2016.pdf

ISO 9001 2015.pdf

ISO45001.pdf

ISO 14001.pdf

FKM-ROHS CANEC23015740909(SZP23-030677).pdf

FKM-REACH CANEC23015740911(SZP23-030677).pdf

FKM-FDA CANEC23015737705(SZP23-030799).pdf

FKM-ELV CANEC23015740913(SZP23-030677)-Final.pdf



We can also produce Automotive Rubber Seals ,Connector Rubber Seals ,Power Tool Rubber seals ,Valve

Rubber Seals ,Pipe Rubber Seals ,Semiconductor Rubber Seals ,Hydraulic Pneumatic Rubber Seals ,Pump

Rubber Seals ,Oil and Gas Seals ,Food Grade Rubber Seals ,Medical Rubber Seals ,Chemical Equipment

Rubber Seals ...etc.

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 2

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 3

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 4

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 5

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 6

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 7

Our Factory



Rui Chen Sealing Co., Ltd was built in 2006, now there are more than 200 staff. The company has

two branches in Guangdong

and Jiangxi, They are Dongguan Rui Chen Sealing Co., Ltd. and Shangrao Rui Chen Sealing Co., Ltd..

In recent years, the company has been supported by ShangRao municipal government and fully enjoy

all the preferential policies

for economic development zone. We will always take "best quality, best service" as our mission, and make

progress together with you, harmony and mutual win!

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 8Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 9Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 10Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 11



Ruichen always meets our customers' requirements. To make sure we produce high-quality o-rings, our company implements the

following general standards:

1) Raw material incoming inspection standard ASTM D2000 & HG/T 2579-2008 & HG/T 2811-1996
2) Public o-ring dimensional tolerance GB/T 3452.1-2005
3) N-level specification for o-ring appearance quality inspection GB/T 3452.2-2007
4) Hardness measurement model Micro O-Ring Testing (Type M system)
5) Hardness using standard ASTM D2240 Rubber Standard Test Method (Shore A)
6) Sampling inspection specification GB/T2828.1-20



Progress
Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 12



Cooperative partner



Ruichen company have cooperated with many superior customers as below , we have complete system and excellent productivity

to serve for you

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 13



International exhibition



Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 14

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 15

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 16

Standard Sizes Fluorine Rubber Sealing Ring Full Inspection O-Ring Gasket for Sealing 17

Why RUICHEN?

Many big companies select RUICHEN for their rubber seals and customized rubber parts because we always

satisfy them in quality, price, delivery, service, etc. At the same time, we also attach great importance to the

small customers in niche markets.Whether your purchase quantity is big or small, you are our valuable partners.

High Quality
We continue to manufacture high-quality products for all customers and pursue 100% customer satisfaction,

which has become one of our core competencies.

Profession
We have rich experience in materials, products, and production and excellent international trade and language

communication skills.

Best Services
From quoting, sampling, production, and shipping to after-sales, our sales will provide you with the best service

so that you can rest assured completely.

10000+ Projects Delivered
Over 10K projects have been sent to our customers worldwide in recent years, and we have received countless

positive comments.

Low Price
Our customers can obtain maximum profits through the ISO management system and intelligent manufacturing

to reduce our costs continuously.

Massive Capacity
Our in-house facilities allow us to get your projects done fast. And thanks to our strong relationship with rapid

materials partners, our capacity is not limited.

Fast Delivery
Unlimited capacity, experienced engineers, and a flexible production system allow us to create your seals and

production parts in a short period.

1000+ Happy Customers
We aim to keep every customer happy with reliable quality, fast turnaround, and excellent services. We want all

our new customers to become long-term customers.

Inquiry Guide



In order to you can get faster and more accurate service, please send an inquiry according to this

page



Enquiries parameters: size, material, hardness, color, tolerance, working environment, purchase

quantity , etc.

1. Size:drawing or sample.

2. Material: Silicone, NBR, EPDM, VITON&FKM, NR, HNBR, SBR, Neoprene, PU,FFKM, etc

3. Hardness: 30 Shore A~90 Shore A

4. Color: according to your request, the most common color is black. The price of the white color

products is litter higher than others.

5. Tolerance: if there is special size requirements, please mention in enquiries. Otherwise, we will

be in accordance with the international standard tolerance execution.

6. Working environment: in order to produce more accurate production you need, please be sure

to inform products work environment. Such as motion situation(is sports or stationary, whether

there is friction), contact medium (exposure to corrosive gas, water vapor, acidic or alkaline liquid),

etc.

7. Purchase quantity: please offer purchase quantity per month/year.

8. Customer information: in order to facilitate we understand more about your company, and

contact you timely, please provide your company's name, phone number, E-mail contacts.
